Minimum Order Quantity:1 set Packaging Details:Standard export package Delivery Time:10-15 days Payment Terms:T/T, Western Union, L/C, MoneyGram Supply Ability:200 sets / month
Product number： MY-QAJ-F4-06
Listing time： 2020/03/26
ConsultationButton Life Testing Machine (MY-QAJ-F4-06), Sheet metal material with white color
Description
Enterprise Culture: The company has always adhered to the production aim of " keep improving and quality first" and has adopted the operation policy of " producing customers to expect equipment and providing customers with considerate service." Based on “ Innovation, Quality and Cost “. Taking " the company's sustainable development" as the grand vision, seeking benefits from management, seeking benefits from quality, and paying equal attention to social and economic benefits. Insist on specialization and refinement, strive to make the enterprise bigger and stronger, develop itself, feedback to the society and build a world-famous brand.
This machine is mainly used for the special life testing machine of frequency converter power supply detection keys. It has the functions of automatic memory of times, power-down memory, cumulative life times, automatic shutdown of set times and so on. Strength correction, adjustable position and spacing, conduction test function. This key life tester is especially suitable for fatigue testing of keys of frequency converter controller.
Tester pictures
Technical Specification
1. Ascending and descending stroke: 220mm (effective space)
2. Test station:two
3. Test times:1~99999999 times
4. Test speed: 10~180 times/ min
5. Maximum click strength:1.0kg (customizable to demand)
6. Action mode:Simultaneous click test Sequential click test
7. Maximum product size:150*170mm
8. Cylinder stroke: 10mm
9. Working temperature: -20 ~ 80 degrees
10. Separable design of work station
11. External Dimension: 950 * 470 *850 mm 12. Control mode: PLC+Touch screen+ Cylinder +Precision pressure regulating valve
13. Power supply: 220v 50/60HZ
14. Power: 200W
Certificates
Partner
Shipment
By sea, by air, by truck, by courier, by train....
FAQ
1. Do you offer after-sales service? How can I ask for that? And how about the warranty?
Every machine from our factory has a 1 year warranty after shipment. Generally, we offer 1 year for the FREE maintenance for our customers. If your machine doesn’t work, you can send E-mail to us and we will try our best to find the problem by email or skype video chat if neccesary. After confirmation of the problem, we can send you new spare parts or provide on-site repair.
2. What’s the delivery term?
Normally, the delivery time is 10-25 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
3. Do you accept customization service? Can I have my logo on the machine?
Yes, of course. We can not only offer standard machines, but also customized machines according to your requirements. And we can also put your logo on the machine.
4. How to install and use the product?
We will send you operating instructions, most of our machine is shipped with a whole part, which means it is already installed, all you need to do is to connect the power cable and start to use. And if possible, we can also install your machine at your location.
